| Grade | PSD/μm | Chemical/% | Test Frequency | 106 Ring 26.9*14.5*11.0mm |
Remark | |
| D50 | C | O | Permeability （μi） | |||
| T8L | 3.0-6.0 | ≤0.15 | ≤0.60 | 10kHz | ≥55 | |
| T8L-I | 6.0-10.0 | ≤0.15 | ≤0.60 | 10kHz | ≥75 | |
| T8S | 4.0-6.0 | ≤0.15 | ≤0.60 | 10kHz | 23-28 | |
| T2L | 4.0-6.0 | ≤1.50 | ≤1.00 | — | — - |
|
| T2A | 3.8-6.0 | ≤1.50 | ≤1.50 | 200KHz | 8.0-13.0 | |
| T8A3(201) | 3.8-7.0 | ≤0.40 | ≤0.90 | 200kHz | ≥19 | 1g磁環(huán) 10.8*8.0*3.3mm |
| T8A5(201) | 5.0-10.0 | ≤0.40 | ≤1.00 | 200kHz | ≥22 | 1g磁環(huán) 10.8*8.0*3.3mm |
| T8SK | 4.0-7.0 | ≤0.30 | ≤1.00 | 100kHz | 21.0-26.0 | coating |
| T8SK-B | 5.5-8.5 | ≤0.30 | ≤1.00 | 100kHz | 22.0-27.0 | coating |
| T8A3 | 3-6 | ≤0.20 | ≤0.80 | 100kHz | 25.0-29.0 | coating |
| T8A3-6JY | 5.0-8.0 | ≤0.20 | ≤0.80 | 100kHz | 26.0-30.0 | coating |
| T8A5 | 3-6 | ≤0.30 | ≤1.00 | 200kHz | 23.0-29.0 | coating |
| T6A | 1.2-2.2 | ≤1.80 | ≤1.80 | 25MHz | 8.0-11.0 | |
| FeSiCr(-500) | 9.0-16.0 | ＜0.20 | ＜0.70 | 200kHZ | ≥27 | coating |
| FeSiCr(-325) | 16.0-20.0 | ＜0.20 | ＜0.70 | 200kHZ | 30-34 | coating |
| H8 | - | - | - | 200kHz | 25 | High temperature resistance |
